Vehicle Accessory Applications

T-Back Lock Core FP662-T-KD

Weather-resistant, six tumbler, double bitted pin actuated T-back style lock core; Compatible with popular bike and car top carries; Two keys included

i-Lock BLUE

Controller / Bluetooth

PATENTED

Power Specification

• 12V DC operation
• Constant Power Source. such as vehicle/machine power
• Low Power consumption mode draws 6 mA continuous of

electrical current in stand by mode

Communication

• 2.4 Ghz RF Bluetooth 4.0

Multi user connectivity

Other devices in s system connect via Bluetooth

• ILock Blue App
• iOS
• Android OS

Outputs

• 3 individual outputs
• 6VDC - 12VDC (+/- 10%)
• Output Current (9A peak, 4.5A continuous, per output)
• Output can be programed to device specifications types via App

Inputs

• 2 inputs via push button or other Normally Open switching device.
• 3.3V supply used for LED illumination
• Voltage supply turned on when connected device is in range.
• Output Control
• Multi-button press responses.
• Multi-output Control (Set up via app)

Environmental

• -20° to 80°C (-4° to 176°F) ~95% RH

522-XA-11

Quarter-Turn Latch

• 90 degree rotation quarter turn
• Includes .62" wide cam by 1" length
• Nickel finish, black knob

502-634-K-30

Compression Trigger Latch

• Key-locking adjustable compression trigger latch
• Black powder textured finish
• Grip range .13" to .84"

2-4891-SS-10

PADDLE LOCK

28430-RSS-J201-03

Whale T-Handle - 3-Point

IP66 rated, Key-locking, Whale Tail compression T-handle with adjustable roller and rubber gasket.
Keyed J201

• Right hand
• 3-point

60lb PNEU Gas Spring EAA-8200-60-01

60lb. PNEU Gas Spring with steel end fittings. 2" stroke. Compressed length 6.4". Extended length 8.4". (1-2 week lead time if no stock)

930-23

Self-Adjusting Draw Latch

• Self-adjusting
• Stainless steel tension springs to help maintain balanced load forces
• Up to 7/16" U-bolt adjustment
• Padlock eye provides for up to a 3/8" diameter padlock shackle
• Hook not included
  • Catch plate options: 9674-B3 (Max load 1,500lbs), 7462 (Max load 1,000lbs), 166-AH (Max load 300lbs)

CL3M | "Rodeo" Cable Lock

       The New Rodeo Lock - UV Protected Cable Lock - Part # CL3M

• Features an industry-first, fully water-protected lock core, making it perfect for protecting your outdoor marine equipment, like a kayak or canoe.
• Triple seal protection blocking essential mechanical components from contaminants and water.
• Anti-tangle cable restraint system with 10 feet of cable length.
• UV protection. Stainless steel springs and nickel-plated zinc core.
