Electro Mechanical
| Part Number | Length | Barrel Length | Spring Return | Position | Connector | Download |
|---|---|---|---|---|---|---|
| S201 | 1.375" | .71875" | No | Off-On | Solder post | Spec sheet |
| S201A | 1.6875" | 1.03125" | Yes | Off-On | Solder post | Spec sheet |
| S203 | 1.4687" | .71875" | No | Off-On | Screw | Spec sheet |
| S203A | 1.78125" | 1.03125" | Yes | Off-On | Screw | Spec sheet |
| S205 | 1.4687" | .71875" | No | Off-On | Spade | Spec sheet |
| S205A | 1.78125" | 1.03125" | Yes | Off-On | Spade | Spec sheet |
| S301 | 1.375" | .71875" | No | On-Off | Solder post | Spec sheet |
| S301A | 1.6875" | 1.03125" | Yes | On-Off | Solder post | Spec sheet |
| S303 | 1.4687" | .71875" | No | On-Off | Screw | Spec sheet |
| S303A | 1.78125" | 1.03125" | Yes | On-Off | Screw | Spec sheet |
| S305 | 1.4687" | .71875" | No | On-Off | Spade | Spec sheet |
| S305A | 1.78125" | 1.03125" | Yes | On-Off | Spade | Spec sheet |
Accessories + Replacement PartsAccessories/Replacement Parts
CHROME ESCUTCHEON
PN: S2310A.ALT
BARREL NUT M19
PN: D9868
