Cam Locks

hgfhgfhfgh

157 Series

Single Bitted Cam Locks

  • 90 degree/180 degree CW/CCW rotation
  • When Masterkeyed, 180 primary key changes available
  • Spline filler included
  • One or two key pulls
  • Two keys included
  • Five tumbler
Part Number Finish Material Keyed Length Keyway Key Blank PN Shelf Pack Master Carton Download
00218 Zinc, chrome Die cast KD AUE .625" JVR - 6 disc 414K342515 25 200 Spec sheet, 3D
00219 Zinc, chrome Die cast KA CAT30 .625" JVR - 5 disc 414K342515 25 200 Spec sheet, 3D
00220 Zinc, chrome Die cast KD .625" JVR - 6 disc 414K342515 25 200 Spec sheet, 3D
02654 Zinc, chrome Die cast MKY M8003 (KD) .625" KS (primary) - 6 disc, KM (master) - 6 disc 263K272518 (primary), 263K272517 (master) 25 200 Spec sheet, 3D
02656 Zinc, chrome Die cast KA CAT60 .625" JVR - 5 disc 414K342515 25 200 Spec sheet, 3D
02659 Zinc, chrome Die cast KA CAT60 .625" JVR - 5 disc 414K342515 25 200 Spec sheet, 3D
02660 Zinc, chrome Die cast KA CAT30 .813" JVR - 5 disc 414K342515 25 200 Spec sheet, 3D
02661 Zinc, chrome Die cast KA CAT30 .813" JVR - 5 disc 414K342515 25 200 Spec sheet, 3D
02665 Zinc, chrome Die cast MKY M8003 (KD) 1.25" KS (primary) - 6 disc, KM (master) - 6 disc 263K272518 (primary), 263K272517 (master) 25 200 Spec sheet
02908 Zinc, chrome Die cast KA CAT30 1.25" JVR - 5 disc 414K332515 25 200 Spec sheet
